Measurement documents
The ORC measurements section includes measurement forms, programs and software, and checklists that cover all aspects of the measurement process. These documents are designed to ensure that all measurements are carried out accurately and consistently, and that all data is recorded correctly.
Measurement Forms
Sail Measurement Stickers
IMS Editor
The IMS Editor is Windows-based software for primary use by measurers to edit, store and distribute IMS measurement data. It is compatible with the ORC Manager software used by rating officers for production of ORC International and ORC Club certificates, as well as its designer's version that includes complete calculations using the ORC VPP (Velocity Prediction Program).
Inclinometer Software
Inclinometer for boats and small ships
JM-Sensors inclinometer is a highly accurate sensor. Each unit is individually calibrated to reach an accuracy on par with a 4 m long pendulum. It can be used for inclining test of boats and small ships. The unit is connected with a 5 m USB cable to a Windows PC. The basic software needed is included. Two software versions are supplied. One intended for the standard eight-weight shift inclining test. It can measure nine individual angles, each for a one minute.
Also a software intended for ORC measurements is included. It can measure 8 or 16 angles as and calculate the RM based on given weight and distance.
Download the datasheet with pricing info: https://www.jmsensors.fi/
JM-Sensors inclinometer is a highly accurate sensor. Each unit is individually calibrated to reach an accuracy on par with a 4 m long pendulum. It can be used for inclining test of boats and small ships. The unit is connected with a 5 m USB cable to a Windows PC. The basic software needed is included. Two software versions are supplied. One intended for the standard eight-weight shift inclining test. It can measure nine individual angles, each for a one minute.
Also a software intended for ORC measurements is included. It can measure 8 or 16 angles as and calculate the RM based on given weight and distance.
Download the datasheet with pricing info: https://www.jmsensors.fi/
